Chapter 4. Browser Operation

Control/Display Description

Outlet Shows the port number of the listed outlet.

Outlet Name Each outlet can be given a distinctive name. The maximum

number of characters is 48.

Confirmation

Required

If this option is enabled (there is a check in the checkbox), a

dialog box comes up asking you to confirm a power operation

before it is performed. If it is disabled (there is no check in the

checkbox), the operation is performed without confirmation.

Delay Time (sec)

Power ON

Sets the amount of time the eco PDU waits after the Power

Button is clicked (see Outlet Status, page 19), before it turns on

the power to the outlet. You must check the Enable Power On

Time Schedule Setting box for this setting to take effect.

See Power On Time Schedule Settings, page 20, for details.

Note: The default delay time is 1 seconds; the maximum is 999

seconds. When a series of outlets are scheduled to be powered

up, they turn on in sequence with a default delay of 10

milliseconds between each outlet.

Delay Time (sec)

Power OFF

Sets the amount of time the eco PDU waits after the Power

Button is clicked (see Outlet Status, page 19), before it turns off

the power to the outlet.

For the System after AC Back option (see below), after the

delay time expires, the eco PDU waits another fifteen seconds,

then shuts the computer down.

The default delay time is 5 seconds. The maximum delay time

is 999 seconds.
