IP Control Box User Manual

3. Provide a valid username and password (set by the administrator), and

select your language. (Options are: English [default]; Traditional Chinese;

Simplified Chinese; Japanese; German; Italian; Spanish; French; Russian;

Korean; Portuguese).

4. Click Login to bring up the browser Main Page.
