f Switch the measuring tool off during transport. When

switching off, the levelling unit, which can be damaged in

case of intense movement, is locked.

Switching On and Off

To switch on the measuring tool, slide the On/Off switch 4 to

the “on” position (when working without automatic level-

ling) or to the “on” position (when working with automat-

ic levelling). Immediately after switching on, the measuring

tool sends laser beams out of the exit openings 1.

f Do not point the laser beam at persons or animals and

do not look into the laser beam yourself, not even from

a large distance.

To switch off the measuring tool, slide the On/Off switch 4 to

the “off” position. When switching off, the levelling unit is

locked.

Deactivating the Automatic Shut-off

When no button on the measuring tool is pressed for approx.

30 minutes, the measuring tool automatically switches off to

save the batteries.

To switch on the measuring tool after automatic shut-off, either

slide the On/Off switch 4 to the “off” position and then switch

the measuring tool on again or press the operating mode button

2 once.

To deactivate the automatic shut-off, keep the operating

mode button 2 pressed for at least 3 s (while the measuring

tool is switched on). Deactivation of the automatic shut-off is

confirmed by brief flashing of the laser beams.

f Do not leave the switched on measuring tool unattend-

ed and switch the measuring tool off after use. Other

persons could be blinded by the laser beam.

To activate the automatic shut-off, switch the measuring tool

off and then on again.

Operating Modes

The measuring tool has several operating modes between

which you can switch at any time:

– Cross and point-line operation: The measuring tool gener-

ates a horizontal and a vertical laser line facing toward the

front as well as a vertical point beam each facing upward

and downward, and a horizontal point beam each facing

toward the front and to both sides.

– 5-point operation: The measuring tool generates a vertical

point beam each facing upward and downward, as well as

a horizontal point beam each facing toward the front and to

both sides.

– Horizontal line operation: The measuring tool generates a

horizontal laser line facing frontward.

– Vertical line operation: The measuring tool generates a ver-

tical laser line facing frontward.

All point beams run at a 90° angle to each other; the laser

lines also cross each other at a 90° angle.

After switching on, the measuring tool is in cross-line and

point-line operation. To change the operating mode, press

the operating mode button 2.

All operating modes can be selected both with and without au-

tomatic levelling.

Automatic Levelling

Working with Automatic Levelling (see figures C–E)

Position the measuring tool on a level and firm support, attach

it to the holder 15 or to the tripod 16.

When working with automatic levelling, push the On/Off

switch 4 to the “ on” position.

After switching on, the automatic levelling function automati-

cally compensates irregularities within the self-levelling range

of ± 4°. The levelling is finished as soon as the laser points or

laser lines do not move any more.

If the automatic levelling function is not possible, e.g. be-

cause the surface on which the measuring tool stands devi-

ates by more than 4° from the horizontal plane, the laser

beams flash. This alarm is deactivated within 10 s after

switching on, in order to allow adjustment of the measuring

tool.

Set up the measuring tool in level position and wait for the

self-levelling to take place. As soon as the measuring tool is

within the self-levelling range of ±4°, the laser beams light up

continuously.

In case of ground vibrations or position changes during oper-

ation, the measuring tool is automatically levelled in again. To

avoid errors by moving the measuring tool, check the position

of the laser beams with regard to the reference points upon

re-levelling.

Working without Automatic Levelling (see figure F)

For work without automatic levelling, push the On/Off switch

4 to the “ on” position. When the automatic levelling is

switched off, the laser lines flash continuously.

When automatic levelling is switched off, you can hold the

measuring tool freely in your hand or place it on an inclinded

surface. The laser beams no longer necessarily run vertical to

each other.

Levelling Accuracy

Influences on Accuracy

The ambient temperature has the greatest influence. Espe-

cially temperature differences occurring from the ground

upward can divert the laser beam.

As thermal fluctuation is largest close to the ground, the

measuring tool, if possible, should be mounted on a commer-

cially available tripod and placed in the centre of the working

area.

Apart from exterior influences, device-specific influences

(such as heavy impact or falling down) can lead to deviations.

Therefore, check the accuracy of the measuring tool each

time before starting your work.

When the accuracy of the horizontal point beams is within the

maximum allowed deviation, then the accuracy of the vertical

point beams and the laser lines is thus also checked.

Should the measuring tool exceed the maximum deviation

during one of the tests, please have it repaired by a Bosch af-

ter-sales service.
