Türkçe | 71
Bosch Power Tools 1 618 C00 50R | (24.1.12)
Uzunlamasna eksenin yatay nivelman hassaslğnn
kontrolü
Bu kontrol işlemi için sağlam bir zeminde A ve B duvarlar
arasnda engelsiz 20 metrelik bir mesafeye ihtiyacnz vardr.
– Ölçme cihazn A duvarnn yaknnda mesnede tespit edin
veya bir sehpaya yerleştirin veya cihaz düz ve sağlam bir
zemine yerleştirin. Ölçme cihazn açn ve 5 nokta işletimini
seçin.
– Ölçme cihaznn uzunlamasna eksenine paralel olarak
seyreden yatay lazer şnn A duvarnn yaknna doğrultun.
Ölçme cihazn nivelmana brakn. Duvardaki lazer
noktasnn merkezini işaretleyin (Nokta I).
– Ölçme cihazn 180° çevirin, nivelman işleminin
yaplmasn bekleyin ve karş B duvarndaki lazer şn
noktasnn ortasn işaretleyin (Nokta II).
– Ölçme cihazn döndürmeden – B duvarnn – yaknna
yerleştirin ve nivelmana brakn.
– Ölçme cihaznn yüksekliğini öyle ayarlayn ki (sehpa veya
gerekiyorsa alta koyacağnz parçalarla), lazer şn
noktasnn ortas daha önce B duvarnda işaretlediğiniz
nokta II ile ayn seviyede olsun.
– Ölçme cihazn yüksekliği değiştirmeden 180° çevirin.
Nivelman yaptrn ve A duvarndaki lazer şn noktasnn
ortasn işaretleyin (Nokta III). Bu esnada nokta III’ün
mümkün olduğu kadar dik veya nokta I’in altnda olmasna
dikkat edin.
– Duvarda işaretlenmiş bulunan nokta I ve III arasndaki d
fark ölçme cihaznn uzunlamasna eksen boyunca
gösterdiği yükseklik sapmasn verir.
2 x 20 m = 40 m’lik ölçme hattndaki müsaade edilen
maksimum sapma:
40 m x ± 0,3 mm/m = ± 12 mm.
Buna göre I ve III noktalar arasndaki fark d en fazla 12 mm
olmaldr.
Çalşrken dikkat edilecek hususlar
f İşaretleme yaparken daima lazer noktasnn veya lazer
çizgisinin ortasn kullann. Lazer noktasnn büyüklüğü
veya lazer çizgisinin genişliği uzaklk ile birlikte değişir.
Sehpa ile çalşmak (aksesuar)
Sehpa, istikrarl ve yüksekliği ayarlanabilir bir ölçme zemini
sağlar. Ölçme cihaznn 1/4" sehpa girişini 7 sehpann 16
veya piyasada bulunan bir fotoğraf makinesi sehpasnn
dişlerine yerleştirin. Piyasada bulunan bir yap sehpasna
tespit için 5/8" sehpa girişini 6 kullann. Sehpann tespit
vidas ile ölçme cihazn skarak tespit edin.
Ölçme cihazn açmadan önce sehpay kabaca doğrultun.
Üniversal tutucu ile tespit (aksesuar)
Üniversal tutucu 15 yardm ile ölçme cihazn örneğin dik
yüzeylere, borulara veya manyetik malzemeye tespit edebilir-
siniz. Üniversal tutucu zemin sehpas olarak da kullanlmaya
uygundur ve ölçme cihaznn yükseklik ayarn kolaylaştrr.
Ölçme cihazn açmadan önce üniversal tutucuyu 15 kabaca
doğrultun.
Ölçme levhas ile çalşmak (aksesuar)
(Baknz: Şekiller A–B)
Ölçme levhas 14 yardm ile lazer işaretini zemine veya lazer
yüksekliğinde duvara aktarabilirsiniz.
Sfr alan ve skala yardm ile istenen yükseklikten fark ölçerek
öteki tarafa aktarabilirsiniz. Bu sayede ölçme cihaznn
aktarlacak yüksekliğe hassas biçimde ayarlanmas gerekmez.
Ölçme levhasnn 14 yanstc bir kaplamas vardr ve bu
kaplama lazer şnnn uzak mesafelerden veya şiddetli güneş
şğnda görünürlülüğünü artrr. Parlaklğn güçlendirildiğini
ancak lazer şnna paralel olarak ölçme levhasna baknca fark
edersiniz.
A
B
20 m
180°
B
A
A
B
d
180°
A
B
