Nivelman otomatiği
Nivelman otomatiği ile çalşmak
(Baknz: Şekiller C–E)
Ölçme cihazn yatay, düz ve sağlam bir zemine yerleştirin ve
üniversal tutucuya 15 veya sehpaya 16 tespit edin.
Nivelman otomatiği ile çalşmak için açma/kapama şalterini 4
“ on” pozisyonuna itin.
Açldktan sonra nivelman otomatiği ± 4°’lik eşitsizlikleri
otomatik nivelman alannda dengeler. Lazer noktalar veya
lazer çizgileri hareketsiz hale gelince nivelman işlemi
tamamlanmş demektir.
Otamatik nivelman mümkün değilse, örneğin ölçme cihaznn
oturduğu yüzey yataklktan 4°’den fazla saptğndan, lazer
çizgileri yanp söner. Açldktan sonraki 10 saniye içinde bu
alarm ölçme cihaznn doğrultulmasna olanak sağlamak üzere
pasifleşir.
Ölçme cihazn yatay olarak yerleştirin ve otomatik nivelman
yapmasn bekleyin. Ölçme cihaz ± 4° otomatik nivelman
alan içine gelince lazer şnlar sürekli olarak yanar.
İşletme esnasndaki sarsnt veya konum değişikliklerinde
ölçme cihaz tekrar otomatik olarak nivelman yapar. Cihazn
yer değiştirmesinden kaynaklanan hatal ölçmelerden kaçn-
mak için nivelman işleminden sonra lazer şnlarnn
pozisyonunu belirli referans noktalarna göre kontrol edin.
Nivelman otomatiği olmadan çalşmak
(Baknz: Şekil F)
Otomatik nivelman işlevi olmadan çalşmak için açma/
kapama şalterini 4 “ on”pozisyonuna itin. Otomatik
nivelman işlevi kapal durumda iken lazer şnlar sürekli olarak
yanp söner.
Nivelman otomatiği kapal iken ölçme cihazn elinizde serbet-
çe tutabilirsiniz veya uygun yere yerleştirebilirsiniz. Bu du-
rumda lazer şnlar zorunlu olarak birbirine dik seyretmezler.
Nivelman hassaslğ
Hassaslğ etkileyen faktörler
En büyük etkiyi çevre scaklğ gösterir. Özellikle zeminden
tavana doğru oluşan scaklk farklar lazer şnn saptrabilir.
Scaklk katmanlaşmas zemine yakn yerlerde en yüksek
derecede olduğundan mümkünse ölçme cihazn piyasadan
temin edebileceğiniz bir sehpaya tespit ederek çalşma
alannn ortasna yerleştirin.
Dş etkiler yannda cihaza özgü etkiler de (örneğin düşme ve
çarpmalar) sapmalara neden olabilir. Bu nedenle her
kullanmdan önce ölçme cihaznn hassaslğn kontrol edin.
Yatay noktasal şnlarn hassaslğ izin verilen maksimum
aralktan fazla sapma gösterirse, dikey noktasal şnlarn ve
lazer çizgilerinin de hasaslğ da kontrol edilir.
Yaptğnz kontrollerde ölçme cihaz maksimum sapma snrn
aşacak olursa, cihaz bir Bosch müşteri hizmetine onarma
gönderin.
Enine eksenin yatay nivelman hassaslğnn kontrolü
Bu kontrol işlemi için sağlam zemin üzerinde, bir duvar
önünde 20 metrelik engelsiz bir ölçme hattna ihtiyacnz
vardr.
– Ölçme cihazn duvardan 20 m uzaklkta mesnede tespit
edin veya bir sehpaya yerleştirin veya cihaz düz ve sağlam
bir zemine yerleştirin. Ölçme cihazn açn ve 5 nokta
işletimini seçin.
– Ölçme cihaznn enine ekseni boyunca seyreden iki yan
lazer şnndan birini duvara doğrultun. Ölçme cihazn
nivelmana brakn. Duvardaki lazer noktasnn merkezini
işaretleyin (Nokta I).
– Yüksekliği değiştirmeden ölçme cihazn yaklaşk
180°çevirin. Cihaz nivelmana brakn ve duvardaki diğer
yan lazer şn noktasnn merkezini işaretleyin (Nokta II).
Bu esnada nokta II’nin mümkün olduğu kadar nokta I’in
üzerinde veya altnda dik olmasna dikkat edin.
– Duvarda işaretlenmiş bulunan nokta I ve II arasndaki d
fark ölçme cihaznn enine eksen boyunca gösterdiği
gerçek yükseklik sapmasn verir.
2 x 20 m = 40 metrelik ölçme hattnda müsaade edilen
maksimum sapma:
40 m x ± 0,3 mm/m = ± 12 mm.
Buna göre nokta I ve II arasndaki d fark en fazla 12 mm
olmaldr.
20 m
d
180°
