Troubleshooting
138
N300 Wireless Dual Band ADSL2+ Modem Router DGND3300v2
Cannot Access the N300 Wireless Modem Router Menu
If you are unable to access the router’s menu from a computer on your local network, check
the following:
• If
you are using an Ethernet-connected computer, check the Ethernet connection
between the computer and the N300 wireless modem router.
• Make
sure your computer’s IP address is on the same subnet as the router. If you are
using the recommended addressing scheme, your computer’s address should be in the
range of 192.168.0.2 to 192.168.0.254.
• If
your computer’s IP address is shown as 169.254.x.x:, it might because recent versions
of Windows and MacOS generate and assign an IP address if the computer cannot reach
a DHCP server. These auto generated addresses are in the range of 169.254.x.x. If your
IP address is in this range, check the connection from the computer to the router and
reboot your computer.
• If
your router’s IP address was changed and you do not know the current IP address,
clear the router’s configuration to factory defaults. This sets the router’s IP address to
192.168.0.1 or http://www.routerlogin.net. This procedure is explained in Restore the
Factory Configuration Settings on p
age 161.
• Make
sure your browser has Java, JavaScript, or ActiveX enabled. If you are using
Internet Explorer, click Refresh to be sure the Java applet is loaded.
• T
ry quitting the browser and launching it again.
• Make sure tha
t you are using the correct login information. The login name is admin and
the default password is password. Make sure that Caps Lock is off when entering this
information.
If the N300 wireless modem router does not save chang
es you have made in the N300
wireless modem router menu, check the following:
• W
hen entering configuration settings, be sure to click the Apply button before moving to
another screen, or your changes are lost.
• Click the Refresh or Reload
button in the Web browser. The changes might have
occurred, but the Web browser might be caching the old configuration.
The Ethernet port LEDs are off. If the Ethernet port LEDs do not light when the Ethernet connection is
made, check the following:
• Make sure that the Ethernet cable connections are secure at the N300
wire
less modem router and computer.
• Make sure that power is turned on to the connected modem or
computer
.
Wireless LEDs are off. If the Wireless LEDs do not come on, verify that the Enab
le Wireless
Router Radio check box is selected on the Advanced Wireless Settings
screen. See Configure Advanced WPS Settings on p
age 27.
Situation Recommended Action
