5. USB Storage
Network storage to share files and back up data
This chapter describes how to access and configure a USB storage drive attached to your
N300 wireless modem router.
USB port
Note: The USB port on the N300 wireless modem router can be used only
to connect USB storage devices like flash drives or hard drives. Do
not connect computers, USB modems, printers, CD drives, or DVD
drives to the N300 wireless modem router USB port.
This chapter includes the following sections:
• USB Drive Requirements on p
age 65
• File Sharing Scenarios on pa
ge 65
• USB Storage Basic Settings on p
age 67
• Configure USB Storage Advanced Settings on page 70
•
Media Server Settings on page 72
•
Unmount a USB Drive on pag
e 72
• Specify Approved USB Devices on page 73
•
Connect to the USB Drive from a Remote Computer on pag
e 73
• Connect to the USB Drive with Microsoft Network Settings on page 74
