NETGEAR VPN Configuration
145
N300 Wireless Dual Band ADSL2+ Modem Router DGND3300v2
Step-by-Step Configuration
To configure the VPN tunnel:
1. Use the VPN Wizard to co
nfigure Gateway A (DGND3300v2) for a gateway-to-gateway
tunnel (see Set Up a Gateway-to-Gateway VPN Configuration on page 90
), being
certain to use appropriate network addresses for the environment.
The LAN addresses used in this example are as follows:
Unit WAN IP LAN IP LAN Subnet Mask
DGND3300v2 14.15.16.17 10.5.6.1 255.255.255.0
FVL328 22.13.24.25 172.23.9.1 255.255.255.0
a. Enter toGW_B for the connection name.
b. Enter 22.23.24.25
for the remote WAN’s IP address.
c. Enter the following:
•
IP Address. 172.23.
9.1
• Subnet Mask. 255.255.255.0
d.
In the Summary screen, click Don
e.
2. Use the VPN Wizard to configure the Gateway B for a gateway-to-gateway tunnel (see Se
t
Up a Gateway-to-Gateway VPN Configuration on page 90), being cert
ain to use
appropriate network addresses for the environment.
a. Enter toGW_A for the con
nection name.
b. Enter 14.15.16.17
for the remote WAN’s IP address.
c. Enter the following:
•
IP Address. 10.5.6.1
•
Subnet Mask. 255.255.255.0
d.
In the Summary screen, click Done
.
