Netgear DGND3300 [47/174] The following information is provided in the logs

Security Settings

N300 Wireless Dual Band ADSL2+ Modem Router DGND3300v2

• To clear the log entries, click the Clear Log button.

• To e-mail the log immediately, click the Sen

d Log button.

The following information is provided in the logs:

Field Description

Date and time The date and time the log entry was recorded.

Source IP The IP address of the initiating device for this log entry.

Target address The name or IP address of the we

bsite or newsgroup visited, or to which access was

attempted.

Action Whether the access was blocked or allowed.
