Netgear DGND3300 [34/174] Security settings
![Netgear DGND3300 [34/174] Security settings](/views2/1205516/page34/bg22.png)
34
3
3. Security Settings
Keep unwanted content out of your network
This chapter describes how to use the content filtering and reporting features of the N300
wireless modem router to protect your network.
This chapter includes the following sections:
• Restrict Access by MAC Address on p
age 35
• Block Access to Internet Sites on p
age 37
• Firewall Rules o
n page 38
• Port Forwarding on p
age 41
• Port Triggering on p
age 43
• Block Access to Internet Services on p
age 45
• Schedule Blocking on p
age 46
• View Logs of Web Access or Attempted Web Access o
n page 46
• Configure Email Alert and Web
Access Log Notifications on page 48
• Set the Time on p
age 49
Note: For information about restricting access to USB storage devices,
see Configure USB Storage Advanced Settings on page 70.
Protect Access to Your N300 Wireless Modem Router
For security reasons, the N300 wireless modem router has its own user name and password.
Also, after a period of inactivity for a set length of time, the administrator login automatically
disconnects. When prompted, enter admin for the user name and password for the
password. You can use procedures in the following sections to change the password and the
amount of time for the administrator’s login time-out.
Note: The user name and password are not the same as a user name or
password you might use to log in to your Internet connection.
