Wireless Settings
28
N300 Wireless Dual Band ADSL2+ Modem Router DGND3300v2
Add More WPS Clients
Note: Your wireless settings remain the same when you add another
WPS-enabled client, as long as the Keep Existing Wireless
Settings check box is selected in the Advanced Wireless Settings
screen (select Wireless Settings under Advanced in the N300
wireless modem router main menu). If you clear this check box,
when you add the client, a new SSID and passphrase will be
generated, and all existing connected wireless clients will be
disassociated and disconnected from the N300 wireless modem
router.
To add a wireless client device that is WPS enabled:
1. Follow the pro
cedures in Use a WPS Button to Add a WPS Client on page 24 or Use
PIN Entry to Add a WPS Client on
page 25.
2. Fo
r information about how to view a list of all devices connected to your N300 wireless
modem router (including wireless and Ethernet connected), see View a List of Attached
Devices o
n page 57.
Add Both WPS and Non-WPS Clients
For non-WPS clients, you cannot use the WPS setup procedures to add them to the wireless
network. You need to record, and then manually enter your security settings (see Manually
Configure Your Wireless Settings on p
age 18).
To connect a combination of non-WPS-enabled and WPS-enabled clients to the N300
wireless modem router:
1. Config
ure the network names (SSIDs), select the WPA/PSK + WPA2/PSK radio button
on the Wireless Settings screen (see Manually Configure Your Wireless Settings on
page 18), and click Ap
ply.
2. On the WP
A/PSK + WPA2/PSK screen, select a passphrase and click Apply. Record this
information to use when you add additional clients.
3. Fo
r the non-WPS devices that you want to connect, open the networking utility and follow
the utility’s instructions to enter the SSID, WPA/PSK + WPA2/PSK security method, and
passphrase.
4. Fo
r the WPS devices that you want to connect, follow the procedure in Use a WPS Button
to Add a WPS Client on p
age 24 or Use PIN Entry to Add a WPS Client on page 25.
Note: To make sure that your new wireless settings remain in effect, verify
that the Keep Existing Wireless Settings check box is selected in
the WPS Settings screen.
