Network Maintenance
54
N300 Wireless Dual Band ADSL2+ Modem Router DGND3300v2
ADSL Port MAC Address The Media Access Control address. This is the unique physical address being
used by the Internet (WAN) port of the N300 wireless modem router.
IP Address The IP address being used by the Internet (WAN) port of the N300 wireless
modem rou
ter. If no address is shown, or is 0.0.0.0, the N300 wireless modem
router cannot connect to the Internet.
Network Type The network type depends upon your ISP.
IP Subnet Mask The IP subnet mask being used by the Internet (WAN) port of the N300
wirel
ess modem router.
Gateway IP
Addre
ss
IP address used as a gateway to the Internet for computers configured to use
DHCP.
Domain Name
Server
The Domain Name Server addresses being used by the N300 wireless modem
router.
A Domain Name Server translates human-language URLs such as
www.netgear.com into IP addresses.
LAN Port MAC Address The Media Access Control address. This is the unique physical address being
used
by the Ethernet (LAN) port of the N300 wireless modem router.
IP Address The IP address being used by the Ethernet (LAN) port of the N300 wireless
modem router. The default is 192.168.0.1 (http://www.routerlogin.net).
DHCP Identifies whether the firmware’s built-in DHCP server is active for the
LAN-att
ached devices.
IP Subnet Mask The IP subnet mask being used by the Ethernet (LAN) port of the N300
wirel
ess modem router. The default is 255.255.255.0.
Modem ADSL Firmware
Version
The version of the firmware.
Modem Status The connection status of the modem.
DownStream
Con
nection
Speed
The speed at which the modem is receiving data from the ADSL line.
UpStream
Con
nection
Speed
The speed at which the modem is transmitting data to the ADSL line.
VPI The Virtual Path Identifier setting.
VCI
The Virtual Channel Identifier setting.
Field Description
