Network Maintenance
60
N300 Wireless Dual Band ADSL2+ Modem Router DGND3300v2
Enable Remote Management Access
The remote management feature allows you to upgrade or check the status of your N300
wireless modem router through the Internet. From the main menu, select Advanced >
Remote Management.
Note: Be sure to change the N300 wireless modem router’s default
configuration password to a very secure password. The ideal
password should contain no dictionary words from any language,
and should be a mixture of letters (both uppercase and lowercase),
numbers, and symbols. Your password can be up to 30 characters.
To configure your N300 wireless modem router for remote management:
1. Select the Tu
rn Remote Management On check box.
2. Under Allow Remote Access By,
specify what external IP addresses will be allowed to
access the N300 wireless modem router’s remote management.
Note: For enhanced security, restrict access to as few external IP
addresses as practical.
