NETGEAR VPN Configuration
153
N300 Wireless Dual Band ADSL2+ Modem Router DGND3300v2
To view or modify the tunnel settings, select the radio button next to the tunnel entry, and then
click Edit.
Step 2: Configure Gateway B (the N300 Wireless Modem
Router at the Regional Office)
This procedure assumes that the computer running the client has a dynamically assigned IP
address.
The computer needs to have a VPN client program in
st
alled that supports IPSec (in this case
study, the NETGEAR VPN ProSafe Client is used). Go to the NETGEAR website
(www.netgear.com) for information about how to purchase the NETGEAR ProSafe VPN
Client.
Note: Before installing the software, be sure to turn off any virus protection
or firewall software you might be running on your computer.
To configure the VPN tunnel:
1. Install the NETGEAR ProSafe VPN Client on the remote computer, and then reboot.
a. You might need to insert your Windows CD to complete the installation.
b.
If you do not have a modem or dial-up adapter inst
alled in your computer, you might
see the warning message stating “The NETGEAR ProSafe VPN Component
requires at least one dial-up adapter be installed.” You can disregard this message.
c. Install the IPSec component. You might have the option to install either the VPN
a
dapter or the IPSec component or both. The VPN adapter is not necessary.
d. The system should show the ProSafe icon (
) in the system tray after rebooting.
e. Double-click the system tray icon to open the Security Policy Editor.
2.
Add a new con
nection.
a. Run the NETGEAR ProSafe Security Policy Editor program, and create a VPN
Con
nection.
b. From the Edit menu of the Security Policy Editor, select Add > Connection. A New
Con
nection listing appears in the list of policies.
