Wireless Settings
31
N300 Wireless Dual Band ADSL2+ Modem Router DGND3300v2
• Restricting access by MAC address. You can use the Wireless Card Access List to
restrict access. See Restrict Access by MAC Address on page 35
.
Wireless Guest Networks
A wireless guest network allows you to provide guests access to your wireless network
without prior authorization of each individual guest. You can configure wireless guest
networks and specify the security options for each wireless guest network.
The Guest Network Settings screen that you se
e depends on the setting in the Wireless
Mode field on the Wireless Settings screen and on which selection you make from the main
menu. The Guest Network selection is grayed out if it is not available. The following table
shows wireless modes, menu selections, and guest networks.
Mode in Wireless Settings
Screen
Menu Selection Guest Network Default SSID Wireless
Compatibility
Up to 300 Mbps at 5 GHz & 54
Mbp
s at 2.4 GHz
(factory default setting)
Guest Network a/n NETGEAR-5G_a_n_Guest1 • 5GHz 802.11a
• 5GHz 802.11n
Guest Network b/g NETGEAR-2.4G_g_Guest1 • 2.4GHz 802.11g
• 2.4GHz 802.11b
Up to 270 Mpbs Guest Network b/g/n NETGEAR-2.4G_n_Guest1 • 2.4GHz 802.11n
• 2.4GHz 802.11g
• 2.4GHz 802.11b
Up to 145 Mbps at 5 GHz & 54
Mb
p
s at 2.4 GHz
Guest Network a/n NETGEAR-2.4G_n_Guest1 • 5GHz 802.11a
• 5GHz 802.11n
Guest Network b/g NETGEAR-2.4G_g_Guest1 • 2.4GHz 802.11g
• 2.4GHz 802.11b
Up to 145 Mbps at 2.4 GHz Guest Network a/n NETGEAR-2.4G_n_Guest1 • 2.4GHz 802.11n
• 2.4GHz 802.11g
• 2.4GHz 802.11b
