Security Settings
41
N300 Wireless Dual Band ADSL2+ Modem Router DGND3300v2
4. Click Apply to have your changes take effect.
The new rule will be listed in the table when you
return to the Firewall Rules screen.
Port Forwarding
Using the port forwarding feature, you can allow certain types of incoming traffic to reach
servers on your local network. For example, you might make a local Web server, FTP server,
or game server visible and available to the Internet.
Use the Port Forwarding screen to configure the
N300 wireless modem router to forward
specific incoming protocols to computers on your local network. In addition to servers for
specific applications, you can also specify a default DMZ server to which all other incoming
protocols are forwarded. The DMZ server is configured in the WAN Setup screen, as
discussed in Configure the WAN Setup Options on p
age 115.”
Before starting, you need to determine which type of service, application, or game you will
p
rovide, and the local IP address of the computer that will provide the service. Be sure the
computer’s IP address never changes.
Send to LAN
Server (inbound
services only)
— Enter the IP address of the computer or
server on your LAN that will receive the
inbound traffic covered by this rule.
WAN Servers These settings determine which Internet locations are covered by the rule, based on their
destina
tion (WAN) IP address. Select the option you want:
• Any. All local
IP addresses are covered by this rule.
• Add
ress range. If this option is selected, you need to fill in the Start and Finish fields.
• Sin
gle address. Enter the required address in the Start fields.
Log This determines whether packets covered by this rule are logged. Select the action you
want:
• Alway
s. Always log traffic considered by this rule, whether it matches or not. This is
useful when debugging your rules.
• Neve
r. Never log traffic considered by this rule, whether it matches or not.
• Ma
tch. Log traffic only if matches this rule. (The action is determined by this rule.)
• Not Match. Log traffic that is considered by this rule, but does not match. (The action is
not determined by this rule.)
Field Outbound Rules Inbound Rules
