Netgear DGND3300 [50/174] Network maintenance
![Netgear DGND3300 [50/174] Network maintenance](/views2/1205516/page50/bg32.png)
50
4
4. Network Maintenance
Administer your network
This chapter describes features to help you manage your N300 wireless modem router. This
chapter includes the following sections:
• Upgrade the Firmware on page 50
•
View N300 Wireless Modem Router Status Information on page
53
• View a List of Attached Devices on p
age 57
• Manage the Configuration File on p
age 58
• Run Diagnostic Utilities and Reboot the Router on p
age 59
• Enable Remote Management Access on p
age 60
• Traffic Meter on pag
e 61
Upgrade the Firmware
The N300 wireless modem router’s firmware (routing software) is stored in flash memory. By
default, when you log in to your N300 wireless modem router, it automatically checks the
NETGEAR website for new firmware and alerts you if there is a newer version.
