Netgear DGND3300 [75/174] Configure windows 2000 and windows xp

USB Storage

N300 Wireless Dual Band ADSL2+ Modem Router DGND3300v2

Configure Windows 98SE and Windows ME

The easiest way to get to your network properties is to go to your desktop, right-click

Network Neighborhood and then click from the main menu,. File and Printer Sharing for

Microsoft Network should be listed. If it is not, click Add and follow the installation prompts.

Note: If you have any questions about File and Printer Sharing, contact

Microsoft for assistance.

Configure Windows 2000 and Windows XP

Right-click the network connection for your local area network. File and Printer Sharing for

Microsoft Networks should be listed. If it is not, click Install and follow the installation

prompts.
