 The VPN Wizard is the recommended method to set up an Auto IPsec policy.

Once the Wizard creates the matching IKE and VPN policies required by the Auto

policy, one can modify the required fields through the edit link. Refer to the online

help for details.

Easy Setup Site to Site VPN Tunnel:

If you find it difficult to configure VPN policies through VPN wizard use easy setup

site to site VPN tunnel. This will add VPN policies by importing a file containing vpn

policies.

6.2 Configuring IPsec Policies

Setup > VPN Settings > IPsec > IPsec Policies

An IPsec policy is between this router and another gateway or this router and a IPsec

client on a remote host. The IPsec mode can be either tunnel or transport depending

on the network being traversed between the two policy endpoints.

 Transport: This is used for end-to-end communication between this router and the

tunnel endpoint, either another IPsec gateway or an IPsec VPN client on a host.

Only the data payload is encrypted and the IP header is not modified or encrypted.

 Tunnel: This mode is used for network-to-network IPsec tunnels where this

gateway is one endpoint of the tunnel. In this mode the entire IP packet including

the header is encrypted and/or authenticated.

When tunnel mode is selected, you can enable NetBIOS and DHCP over IPsec.

DHCP over IPsec allows this router to serve IP leases to hosts on the remote LAN. As

well in this mode you can define the single IP address, range of IPs, or subnet on both

the local and remote private networks that can communicate over the tunnel.
