Unified Services Router User Manual

3.2 WAN Configuration

Setup > Internet Settings > WAN1 Setup

You must either allow the router to detect WAN connection type automatically or configure manually

the following basic settings to enable Internet connectivity:

 ISP Connection type: Based on the ISP you have selected for the primary WAN link for this

router, choose Static IP address, DHCP client, Point-to-Point Tunneling Protocol (PPTP), Point-

to-Point Protocol over Ethernet (PPPoE), Layer 2 Tunneling Protocol (L2TP). Required fields for

the selected ISP type become highlighted. Enter the following information as needed and as

provided by your ISP:

 PPPoE Profile Name. This menu lists configured PPPoE profiles, particularly useful when

configuring multiple PPPoE connections (i.e. for Japan ISPs that have multiple PPPoE support).

 ISP login information. This is required for PPTP and L2TP ISPs.

 User Name

 Password

 Secret (required for L2TP only)

 MPPE Encryption: For PPTP links, your ISP may require you to enable Microsoft Point -to-Point

Encryption (MPPE).

 Split Tunnel (supported for PPTP and L2TP connection). This setting allows your LAN hosts to

access internet sites over this WAN link while still permitting VPN traffic to be directed to a VPN

configured on this WAN port.

 If split tunnel is enabled, DSR won‘t expect a default route from the ISP server. In such case, user

has to take care of routing manually by configuring the routing from Static Routing page.

 Connectivity Type: To keep the connection always on, click Keep Connected. To log out after the

connection is idle for a period of time (useful if your ISP costs are based on logon times), click Idle

Timeout and enter the time, in minutes, to wait before disconnecting in the Idle Time field.

 My IP Address: Enter the IP address assigned to you by the ISP.

 Server IP Address: Enter the IP address of the PPTP or L2TP server.

 DSR-150/150N/250/250N doesn‘t have a dual WAN support.

3.2.1 WAN Port IP address

Your ISP assigns you an IP address that is either dynamic (newly generated each time you lo g in) or

static (permanent). The IP Address Source option allows you to define whether the address is
