9
English
Charger
SPECIFICATIONS
Cordless disc grinder
Model G14DSL
Voltage 14.4V
No-Load speed 9300 min
-1
Wheel
outer dia. × hole dia. 115 × 22 mm
peripheral speed 80 m/s
Rechargeable battery BSL1430: Li-ion 14.4 V (3.0 Ah, 8 cells)
Weight 1.9 Kg
1 Depressed center wheel ........ 1
2 Wrench ..................................... 1
G14DSL 3 Charger ..................................... 1
(2LSCK) 4 Battery ...................................... 2
5 Plastic case .............................. 1
6 Battery cover ........................... 1
G14DSL Without charger, battery, plastic
(NN) case and battery cover
STANDARD ACCESSORIES
Standard accessories are subject to change without
notice.
APPLICATIONS
䡬 Removal of casting fin and finishing of various
types of steel, bronze and aluminum materials and
castings.
䡬 Grinding of welded sections or sections cut by
means of a cutting torch.
䡬 Grinding of synthetic resins, slate, brick, marble, etc.
䡬 Cutting of synthetic concrete, stone, brick, marble,
and similar materials.
BATTERY REMOVAL/INSTALLATION
1. Battery removal
Hold the handle tightly and push the battery latch
to remove the battery (See Fig. 1 and 2).
CAUTION
Never short-circuit the battery.
2. Battery installation
Insert the battery while observing its polarities (See
Fig. 2).
Model UC18YRSL
Charging voltage 14.4 V 18 V
Weight 0.6 kg
CHARGING
Before using the power tool, charge the battery as follows.
1. Connect the charger’s power cord to a receptacle.
When the power cord is connected, the charger’s
pilot lamp will blink in red. (At 1-second intervals)
2. Insert the battery into the charger.
Firmly insert the battery into the charger until the
line is visible, as shown in Fig. 3, 4.
3. Charging
When inserting a battery in the charger, charging
will commence and the pilot lamp will light
continuously in red.
When the battery becomes fully recharged, the pilot
lamp will blink in red. (At 1-second intervals) (See
Table 1)
(1) Pilot lamp indication
The indications of the pilot lamp will be as shown
in Table 1, according to the condition of the charger
or the rechargeable battery.
䡬 Do not place electrically conductive cuttings, nails,
steel wire, copper wire or other wire in the storage
case.
䡬 Either install the battery in the power tool or store
by securely pressing into the battery cover until
the ventilation holes are concealed to prevent short-
circuits. (See Fig. 1)
01Eng_G14DSL_EE 08/2/29, 18:179
