Icom IC-2720H [21/96] Panel description
![Icom IC-2720H [21/96] Panel description](/views2/1074425/page21/bg15.png)
4
1
PANEL DESCRIPTION
New2001
1
tAM INDICATOR (p. 64)
Appears when AM mode is selected.
yFREQUENCY READOUT
Shows the operating frequency, set mode contents, etc.
• Frequency decimal point blinks while scanning. (p. 41)
•“d” appears in place of the 1st digit while the DTMF memory
function is in use. (p. 48)
uMEMORY CHANNEL NUMBER INDICATORS
➥ Shows the selected memory channel number. (p. 29)
➥ Shows the selected bank initial. (p. 35)
➥ “C” appears when the call channel is selected. (p. 38)
➥ “L” appears when the lock function is activated. (p. 15)
iSKIP INDICATOR (p. 44)
Appears when the displayed memory channel is specified
as a skip channel.
oMEMORY INDICATOR (pgs. 12, 29)
Appears when memory mode is selected.
!0S/RF INDICATORS
➥ Shows the relative signal strength while receiving sig-
nals. (p. 16)
➥ Shows the output power level while transmitting. (p. 20)
!1OUTPUT POWER INDICATORS
“LOW” appears when low output power; “MID” appears
when middle output power is selected.
No indicator appears when high output power is selected.
!2BUSY INDICATOR
➥ Appears when a signal is being received or the squelch
is open. (p. 16)
➥ Blinks while the monitor function is activated. (p. 16)
IC-2720H_2.qxd 03.5.13 9:45 Page 4 (1,1)
