9 DTMF MEMORY ENCODER
New2001
D
Programming a DTMF code— via microphone
z Push [FUNC] then [
LOW
6(DTMF)] to turn the
DTMF encoder ON.
•
“d” appears in place of the main band’s 100 MHz digit.
x Push [
SET
B(D-OFF)] to enter the DTMF memory
programming condition.
c Push [Y] or [Z] to select the desired DTMF
memory channel.
v Push the desired digit keys.
• When the first digit is input, previous memory contents
are cleared automatically.
•“E” stands for “
MM
” and “F” stands for “# .”
• Push [Y]/[Z] and repeat this step if you make a mistake.
• The S/RF indicator shows the digit group. The indication
increases every 6 digits.
b Push [VFO/LOCK] to exit the programming condition.
• The [
CLR
A(MW)] key cannot be used to exit. If pushed, code “A”
is input. Reprogram in such a case.
DTMF
[EXAMPLE]: Programming “5428AB453” into DTMF memory channel “d4.”
MAIN
T X
M
MAIN
T X
M
MAIN
T X
M
MAIN
T X
M
MAIN
T X
M
MAIN
T X
M
MAIN
T X
M
Push
Push
Push
Push
Push then .
IC-2720H_2.qxd 03.5.13 9:45 Page 49 (1,1)
