D Optional MB-85 installation
When using the optional MB-85 (
COMBINATION BRACKET
), you
can install the control head of the IC-2720H in one of 2 meth-
ods. A 20 cm (7
7
⁄8″) remote control cable is supplied for con-
nection, and connect the cable before attaching the bracket to
the main unit is recommended.
