Icom IC-2720H [4/96] Table of contents supplied accessories
![Icom IC-2720H [4/96] Table of contents supplied accessories](/views2/1074425/page4/bg4.png)
New2001
iii
TABLE OF CONTENTSSUPPLIED ACCESSORIES
q DC power cable (3 m) ………………………………………1
w Mobile mounting bracket …………………………………1
e Microphone (HM-133)* ……………………………………1
r Fuse (20 A) …………………………………………………1
t Mounting screws, nuts and washers …………………1 set
y Microphone hanger …………………………………………1
u Remote controller bracket (MB-84) ………………………1
i Mounting screws, nuts and washers for MB-84 ……1 set
o Separation cable
†
(3.5 m; 11.5 ft) …………………………1
*HM-118N
HAND MICROPHONE
or HM-118TN/TAN
DTMF MICROPHONE
supplied versions are also available.
†
A ferrite core is adapted for the USA version.
qw e
r
ty
uio
FOREWORD ........................................................................................... i
IMPORTANT ............................................................................................ i
EXPLICIT DEFINITIONS ......................................................................... i
PRECAUTION ........................................................................................ ii
SUPPLIED ACCESSORIES .................................................................. iii
TABLE OF CONTENTS ......................................................................... iii
QUICK REFERENCE GUIDE ........................................................... I–XII
■ Installation ....................................................................................... I
■ Your first contact ......................................................................... VIII
■ Repeater operation ........................................................................ X
■ Programming memory channels.................................................... XI
1 PANEL DESCRIPTION ............................................................... 1–10
■ Front panel— controller ................................................................. 1
■ Function display ............................................................................. 3
■ Main unit ........................................................................................ 5
■ Microphone (HM-133) .................................................................... 7
■ Microphone keypad ........................................................................ 8
■ Optional microphones (HM-118N/TN/TAN)................................... 10
2 SETTING A FREQUENCY ........................................................ 11–15
■ Preparation ................................................................................... 11
■ Using the tuning dial .................................................................... 13
■ Using the [Y]/[Z] keys ................................................................. 13
■ Using the keypad ......................................................................... 13
■ Tuning step selection ................................................................... 14
■ Lock functions .............................................................................. 15
3 BASIC OPERATION ................................................................. 16–21
■ Receiving ..................................................................................... 16
■ Monitor function ........................................................................... 16
■ Squelch attenuator ....................................................................... 17
■ V/V, U/U simultaneous receive (Para-watch) ............................... 18
■ Sub band mute/sub band busy beep ........................................... 19
■ Transmitting ................................................................................. 20
IC-2720H_2.qxd 03.5.13 9:45 Page iii (1,1)
