76
13
SPECIFICATIONS AND OPTIONS
New2001
13
• Squelch sensitivity
†
(threshold) : Less than 0.13 µV
• Selectivity
†
(typical) :
Wide More than 12 kHz/6 dB
Less than 30 kHz/60 dB
Narrow
(USA only) More than 6 kHz/6 dB
Less than 20 kHz/60 dB
• Spurious and image rejection
†
: More than 60 dB
•
AF output power
†
(at 13.8 V DC)
: More than 2.4 W at 10% distortion with an
8 Ω load
• Ext. speaker connectors : 3-conductor 3.5 (d) mm (
1
⁄8″)/8 Ω
†
Guaranteed 144–148 MHz and 430–440 or 440–450 MHz ranges only.
■ Options
HM-133
REMOTE
-
CONTROL MICROPHONE
Wired remote control microphone with key backlight. Same as that
supplied with the transceiver.
HM-118TAN/TN
DTMF MICROPHONE
HM-118N
HAND MICROPHONE
HS-62
FLEXIBLE MOBILE MICROPHONE
+ HS-15SB
SWITCH BOX
+ OPC-589
ADAPTER CABLE
For all-round mobile operation.
OPC-1154/OPC-1155
SEPARATION CABLES
A ferrite core is supplied with the OPC-1155 for the USA version.
Same as that supplied with the transceiver. 3.5 m (11.5 ft)
OPC-1156
CONTROLLER EXTENSION CABLE
Extends the supplied separation cable 3.5 m (11.5 ft)
MB-84
REMOTE CONTROLLER BRACKET
Same as that supplied with the transceiver.
MB-85
COMBINATION BRACKET
Used for single-body installation. 20 cm (7
7
⁄8 in) remote control cable
is supplied.
MB-65
MOUNTING BASE
Mounts the remote controller on to variety of place in vehicle. MB-84
is required for mounting.
MB-17A
MOBILE MOUNTING BRACKET
One-touch bracket. Transceiver main unit easily attached or re-
moved.
OPC-440/OPC-647
MIC EXTENSION CABLES
OPC-440: 5.0 m (16.4 ft); OPC-647: 2.5 m (8.2 ft)
OPC-441
SPEAKER EXTENSION CABLE
5.0 m (16.4 ft)
SP-7/SP-10
EXTERNAL SPEAKERS
SP-7: For base station use. Cable length: 1.0 m; 3.3 ft
SP-10: For all-round mobile operation. Cable length: 1.5 m; 4.9 ft
OPC-347/1132
DC POWER CABLES
OPC-347: 7.0 m (23 ft)
OPC-1132: 3.0 m (9.8 ft) Same as that supplied with the transceiver.
CS-2720
CLONING SOFTWARE
+ OPC-478U
CLONING CABLE
Provides quick and easy programming items, such as memory chan-
nels, set mode contents for local repeater frequencies, via PC’s USB
terminal. RS-232C type cloning cable, OPC-478, also available.
OPC-474
CLONING CABLE
Used for data cloning between transceivers.
All stated specifications are subject to change without notice or obligation.
