75
SPECIFICATIONS AND OPTIONS
New2001
13
■ Specifications
DD
GENERAL
• Frequency coverage : (unit: MHz)
*
1
Guaranteed: 144–148 MHz range only.; *
2
Guaranteed: 440–450 MHz range for the USA,
430–440 MHz for the General version; *
3
Not guaranteed; *
4
824.010 to 848.990 and
869.010 to 893.990 MHz ranges are inhibited for USA version and not guaranteed.
• Type of emission : FM, AM (Receive only)
• Number of memory channels : 212 (incl. 10 scan edges and 2 calls)
• Frequency resolution : 5, 10, 12.5, 15, 20, 25, 30, 50 kHz
• Operating temperature range : –10°C to +60°C; +14˚F to +140˚F
• Frequency stability : ±10 ppm
(–10°C to +60°C)
• Power supply requirement : 13.8 V DC ±15%
• Current drain
(at 13.8 V DC: approx.):
Transmit at 50 W 12 A
Receive standby 1.2 A
(simultaneous receive) max. audio 1.8 A
• Antenna connector : SO-239
(50 Ω)
• Dimensions (proj. not included) :
Main Unit 140(W) × 40(H) × 187(D) mm
5
1
⁄2(W)×1
9
⁄16(H)×7
3
⁄8(D) in
Remote controller 140(W) × 50(H) × 24.5(D) mm
5
1
⁄2
(W)×1
31
⁄32
(H)×
31
⁄32
(D) in
• Weight
(approx.) :
Main unit
(incl. separation cable)
1.25 kg; 2 lb 12 oz
Remote controller 150 g; 5.3 oz
DD
TRANSMITTER
• Modulation system : Variable reactance frequency modulation
• Output power : VHF 50/15/5 W* (approx.)
UHF 35/15/5 W* (approx.)
*25/15/5 W only for the Taiwan version.
• Max. frequency deviation : ±5.0 kHz (wide)
±2.5 kHz (narrow: Left band only)
• Spurious emissions : Less than –60 dB
• Microphone connector : 8-pin modular
(600 Ω)
DD
RECEIVER
• Receive system : Double-conversion superheterodyne
• Intermediate frequencies :
Left band 1st: 38.85 MHz, 2nd: 450 kHz
Right band 1st: 46.05 MHz, 2nd: 455 kHz
• Sensitivity
(FM: at 12 dB SINAD/AM: at 10 dB S/N):
Frequency range Left band (µV) Right band (µV)
118–159.995 MHz 0.18/0.45
160–173.995 MHz 0.32/— 0.2/—
174–179.995 MHz 0.32/— N/A
180–219.995 MHz 3.5/— N/A
220–259.995 MHz 0.32/0.79 N/A
260–349.995 MHz 3.2/5.6 N/A
350–374.995 MHz 0.32/1.0 N/A
375–399.995 MHz 0.22/0.63
400–429.995 MHz 0.22/—
430–450 MHz 0.18/—
450.005–499.995 MHz 0.22/—
500–549.995 MHz 0.32/— 0.22/—
810–879.990 MHz N/A 0.45/—
880–999.990 MHz N/A 1.0/—
Version Left Band Right Band
USA, Rx: 118–549.995*
1
Rx: 118–173.995*
1
, 375–549.995,*
3
General Tx: 144–148, 430–450*
2
810–999.99*
4
Tx: 144–148, 430–450*
2
Asia
Rx: 136–173.995,*
1
430–440 Rx: 136–173.995,*
1
430–440
Tx: 144–148, 430–440 Tx: 144–148, 430–440
Australia Tx/Rx: 144–148, 430–440
Taiwan,
Tx/Rx: 144–146, 430–440
Korea
IC-2720H_2.qxd 03.5.13 9:45 Page 75 (1,1)
