PS-link 3108SP [12/147] Switch windows or menu

Button

Description

Enter 6, M, N, or O; or enable or disable arming.

Enter 7, P, Q, R, or S; or take a snapshot.

Enter 8, T, U, or V.

Enter 9, W, X, Y, or Z.

Enter 0 or a space.

Delete

Switch the input method.

Auxiliary function button.

Exit the current window.

Switch to the next tab.

 , , , : Switch windows or menu

items; or control rotation directions of a PTZ

camera when the PTZ toolbar is closed

 , : Rewind or forward 30 seconds in full

screen.

 , : Variable-speed forward or rewind in

full screen.

 : Confirm an operation; or start or pause

playback.
