PS-link 3108SP [66/147] Playback by image
![PS-link 3108SP [66/147] Playback by image](/views2/1913196/page66/bg42.png)
59
1. In the playback window, click on the screen toolbar.
2. Click Refresh and then wait for the NVR to read the external storage
device.
3. Select the desired recording file and then click to start playback.
Playback by Image
Specify an image type (for example, Normal or Motion) to search for and
play images from one or more cameras during a specified time period.
1. In the playback window, click Video Retrieval, select Picture Search
from the drop-down list in the upper left corner.
2. Select a type from the Type drop-down list in the upper right corner.
3. Select the desired camera(s), set the desired time period, and then
click Search.
4. Click the desired file to start playback.
Playback by POS
Use this function to play recordings of a POS machine.
1. In the playback window, click Video Retrieval, select POS Search
from the drop-down list in the upper left corner.
2. Select the desired camera, set the time period, enter keywords and
then click Search.
NOTE!
Keywords allow special characters & (means AND) and | (means OR).
3. Click to display overlay content.
4. Click to start playback.
