PS-link 3108SP [88/147] Object removed

Object Removed

Detect object removed from specified areas and trigger an alarm.

1. Click VCA > VCA Config > Object Removed.

2. Select the camera and select Enable to enable detection of objects

removed.

3. Click to draw detection areas.

NOTE!

When drawing a detection area, you can use up to 6 points to specify the

area. Up to 4 detection areas area allowed.

4. Set sensitivity and time threshold:

 Sensitivity: The higher the sensitivity, the more likely an object will

be detected.

 Time Threshold: An alarm will be triggered when the length of time

an object is missing in specified areas exceeds this value.

5. Click right to Trigger Actions and set action(s) to trigger. For

more details, see Alarm-Triggered Actions.
