PS-link 3108SP [62/147] Playback by camera and date

Playback by Camera and Date

Use this method to search and play recordings by camera and date.

1. Click on the preview window, then right click and choose Playback

to start playback.

NOTE!

In playback window, you can select multiple cameras for synchronous

playback. Clicking Max. Camera selects the maximum number of cameras

allowed, and clicking Close All stops playback for all cameras. The

performance varies with NVR model.

2. Select the desired date on the calendar and then click to start

playback. Double-clicking the date will start playback directly.
