52
Other Recording and Snapshot Types
Other recording and snapshot types:
Event: Including the types below and VCA. Any of these types will
trigger event recording/snapshot.
Motion detection AND alarm triggered (M and A for short):
recording or snapshot is triggered only when a motion detection
alarm AND an input alarm occur simultaneously.
Motion detection OR alarm triggered (M or A for short): recording
or snapshot is triggered when a motion detection alarm OR an input
alarm occurs.
When you choose an Event type of recording or snapshot, make sure you
have enabled the corresponding alarm function and configured alarm-
triggered recording/snapshot. The configuration steps are similar. See
Motion Detection Recording and Snapshot for more details.
7 Playback
Instant Playback
Instant playback plays the video recorded during the last 5 minutes and
30 seconds. If no recording is found, it means there is no recording during
this period.
1. Click the desired window, and then click on the toolbar to start
instant playback.
2. You may drag the slider to control the progress. Pause and resume
as needed.
