PS-link 3108SP [82/147] Audio detection

2. Select the camera and then select Enable to enable cross line

detection.

3. Draw detection line(s). Up to four are allowed. Set detection rules,

including entrance direction, sensitivity.

4. Click right to Trigger Actions and set action(s) to trigger. For

more details, see Alarm-Triggered Actions.

5. (Optional) Click right to Arming Schedule and then set the time

when actions will be triggered.

6. Click Apply to save the settings.

Audio Detection

An audio detection alarm occurs when a camera detects a sudden change

in sound volume.

1. Click VCA > VCA Config > Audio Detection.

2. Select the camera and then select Enable to enable audio detection.
