6. (Optional) Click right to Arming Schedule and then set the time
when actions will be triggered.
7. Click Apply to save the settings.
VCA Search
VCA means Video Content Analysis. VCA search searches VCA data
including behavior, human face, and people counting. Only certain NVR
models support this function. You need to select Save VCA Images under
VCA > VCA Config > Basic before using behavior search and face search
functions.
Face Search
Use face search to search for recordings triggered by detected faces.
1. Click VCA > VCA Search > Face.
2. Select cameras, set a search period, and then click Search. Search
results are displayed.
3. View search results in a chart or table. Back up search results
(including images and recordings) as needed. To view videos
recorded when the face was detected (around 10 seconds before
and after), click the play button. The following shows an example.
