2. In the login dialog box, enter the correct username and password
(123456 for admin) and then click Login.
CAUTION!
The default password is intended only for your first login. We strongly
recommend you set a strong password to ensure account security.
Strong: contains at least 8 characters from at least three of the four
types: upper-case letter, lower-case letter, special character, digit.
Medium: contains at least 8 characters from two of the four types:
upper-case letter, lower-case letter, special character, digit.
Weak: contains less than 8 characters from only one of the four
types: upper-case letter, lower-case letter, special character, digit.
3 Live View
The Live View page is displayed when you are logged in. The following
figure shows an example.
