PS-link 3108SP [14/147] Initial configuration
![PS-link 3108SP [14/147] Initial configuration](/views2/1913196/page14/bge.png)
7
Button
Function
UP, DOWN,
LEFT, RIGHT,
ENTER
Press UP, DOWN, LEFT and RIGHT to navigate
between menu items or shift focus.
In PTZ control mode, press UP, DOWN, LEFT, and
RIGHT buttons to select the corresponding buttons on
the screen, and then press ENTER to activate the
selection.
In live view mode, press UP to start sequence in full
screen. Pressing UP again starts sequence with three
windows on the screen. Press DOWN to open the
playback window.
Press ENTER to confirm an operation or to display a
selected drop-down list. In playback mode, press
ENTER to play or pause in full screen mode.
UP and DOWN: Variable speed forward or rewind in
full screen.
LEFT and RIGHT: Rewind or forward 30 seconds in full
screen.
Fn
Press to navigate to the next window when multiple
windows are displayed.
Esc
Exit.
Alphanumeric
buttons
Switch to the corresponding channel in live view
mode.
Input numbers and characters in edit mode.
Shift
Switch menu items.
Del
Remove characters or spaces on the left of the cursor.
2 Initial Configuration
Preparation
Make sure that at least one monitor is correctly connected to the
VGA or HDMI interface on the rear panel of the NVR.
