PS-link 3108SP [54/147] Motion detection snapshot

4. Configure motion detection recording: click right to Trigger

Actions, click the Recording tab, select the desired camera, and then

click OK.

5. (Optional) Configure an arming schedule (time when actions will be

triggered): click right to Arming Schedule and then set time

periods as needed.

6. Set a recording schedule under Storage > Recording. For the

detailed steps, see Draw or Edit a Schedule. Make sure the schedule

type is Motion. The set schedule appears in green, which stands for

motion detection recording. The following figure shows an example.

Motion Detection Snapshot

Motion detection snapshot is similar to motion detection recording. You

need to enable and configure motion detection alarm first (see steps 1 to

3 in Motion Detection Recording for details), and then proceed with the

following steps.

1. Set motion detection snapshot under Alarm > Motion: click right

to Trigger Actions. In the window displayed, click the Snapshot tab,

select the desired camera, and then click OK.
