136
The NVR, IP cameras, and PC are connected on a private network (or LAN).
The IP cameras can be connected to the NVR directly or via a switch. The
PC is installed with surveillance management software. You can manage
the NVR and the connected IP cameras using the surveillance software or
through the monitor.
Typical Application 3
The NVR and the connected IP cameras are located on a private network
(or LAN), and you manage these devices through the cloud server, a cloud
solution for device management over Internet. After registering a cloud
account and properly configuring your network devices (including router),
you can manage your NVR and the connected IP cameras from a PC or a
mobile phone.
Appendix B Acronyms
Acronym
Description
CBR
Constant Bit Rate
DDNS
Dynamic Domain Name Service
DHCP
Dynamic Host Configuration Protocol
DST
Daylight Saving Time
DVS
Digital Video Server
FTP
File Transfer Protocol
