PS-link 3108SP [58/147] Holiday snapshot

3. Click OK. The holiday appears in the list.

4. Click Storage > Recording and then set a recording schedule as

described in Draw or Edit a Schedule. Make sure Holiday is selected

in the Select Day drop-down list. In the following example, motion

detection recording is enabled on the set holiday.

Holiday Snapshot

Holiday snapshot is similar to holiday recording. First you set holidays

under System > Time > Holiday, and then configure a snapshot schedule

under Storage > Snapshot. Set a snapshot schedule as described in

Scheduled Recording. Make sure Holiday is selected from the Select Day

drop-down list.
