Руководство по Эксплуатации Страница: 101

PS-link 3108SP [101/147] Vehicle control

5. Click Save. Check management server status in the page's lower left

corner. A green icon means the camera is connected to the

Video&Image database. Now configuration on the camera is

complete.

Vehicle Control

Vehicle control allows you to view license plate recognition results. To use

this function, you need to configure in Video&Image Database, add plate

list, and set vehicle monitoring task.

Video&Image Database

See Video&Image Database for details.

Add Plate List

1. Click VCA > Vehicle Control > Plate List.

2. Click to add a plate list.

Note:

DefaultList is created by default. Click to modify the list name.

3. Add plate number(s) to plate list.
