124
NOTE!
The test packet size is 3000 bytes by default and can be changed as
needed.
To capture and save packets, select the USB storage device, specify the
port number and IP address, and then click right to the desired NIC.
The captured packets are saved as a backup file in the root directory of
the USB storage device. You may click Open to view the file.
NOTE!
The packet size is 1520 byes by default and can be changed as
needed.
The backup file of the captured packets is named in NIC
name_time.pcap format.
Packets cannot be captured if it is already started on the Web
interface.
If you use PPPoE, a virtual NIC will appear in the list after the dial-up
succeeds, and you may capture packets sent to and from this NIC.
Network Settings
Click Maintain > Network Info > Network to view network settings.
PoE/Network Port Status
Only certain NVR models support this function.
Click System > Network Info to view port status. A blue port indicates that
the port is in use. For PoE models, power information will be displayed.
