113
Time Synchronization
Use this function to synchronize camera time with the NVR. Time sync is
enabled by default, and cameras will synchronize time with the NVR
after getting online, and then synchronize once every 30 minutes.
1. Click System > Time > Time Sync.
2. Select Sync Camera Time and then click Apply.
CAUTION!
Use this function with caution if you have more than one NVR on the
network. An IP camera synchronizing time with multiple NVRs at the same
time will cause chaotic recordings.
POS Configuration
This function is intended for the scenario such as in a café or a
supermarket where the NVR is connected to a POS machine. When
configured properly, the NVR obtains data from the POS machine and
displays information in form of text with video images on the monitor.
Only certain NVR models support this function.
1. Click System > POS.
2. Click Add and then complete settings in the window displayed.
