Руководство по Эксплуатации Страница: 37

PS-link 3108SP [37/147] Operations take ceiling mount and fisheye 3ptz as an example

Mounting Mode Display Mode Description

Desktop mount

360°Panoramic+1PTZ

180°Panoramic

Fisheye+3PTZ

Fisheye+4PTZ

360°Panoramic+6PTZ

Fisheye+8PTZ

Wall mount

Original Image

Panoramic

Panoramic+3PTZ

Panoramic+4PTZ

Panoramic+8PTZ

Operations: Take Ceiling Mount and Fisheye+3PTZ as an example:
