PS-link 3108SP [42/147] Advanced settings

White balance

1. Click the White Balance tab.

2. Adjust the settings on this tab. Some important parameters are

described in the table below.

Parameter Description

White Balance

Adjust the red or blue offset of the image:

 Auto: The camera adjusts the red or blue offset

automatically according to the lighting condition

(the color tends to be blue).

 Finetune: Allow you to adjust the red or blue offset

manually.

Red Offset Adjust the red offset manually.

Blue Offset Adjust the blue offset manually.

Advanced settings

1. Click the Advanced tab.

2. Use defog to improve image quality in foggy days.
