File Management
File management allows you to manage video clips, tags, snapshots taken
during playback, and lock or unlock files.
1. Take snapshot during playback.
a. Click in the playback window to take a snapshot of the
desired image.
b. Click and then click the Playback Image tab to view the
snapshot.
c. Select the desired image file(s) and then click Backup to save
them to the storage device.
NOTE!
The image resolution depends on the resolution from the output interface
and the number of windows displayed when the snapshot is taken.
2. Lock files.
Use this function to lock a recording file so it will not be overwritten. To
lock a recording file will prevent all the files stored in the same disk
partition (254.4M in size) from being overwritten.
a. Click for the recording you want to lock in the playback
window.
b. Click and then click the Locked File tab to view the locked
file. To unlock a file, click , and the icon changes to . To back
up a file, select the file and then click Backup.
