23
NOTE!
First you need to enable port mapping at Setup > Port > Port Mapping on
the IP device's Web interface.
1. Click Camera > Camera, click Custom Add.
2. Choose an option:
By IP
a. On the IP device's Web interface, go to Setup > Port > Port
Mapping, find the external IP (public IP) and external port number.
b. On the NVR: Select a protocol, enter the above-mentioned IP
address and port number, enter the username and password.
c. Click OK.
By MyDDNS
d. On the IP device's Web interface, go to Setup > Network > DDNS,
enable DDNS, select MyDDNS, set a domain name and get the server
address.
NOTE!
After setting the domain name, check that you can use the device
address to access the IP device's Web interface.
Make sure the MyDDNS server and the NVR are connected (ping the
MyDDNS server from the NVR).
e. On the NVR: Select a protocol, enter the above-mentioned
server address, domain name, username and password.
f. Click OK.
By a domain name
a. On the IP device's Web interface, go to Setup > Network > DDNS,
enable DDNS, select DynDNS or NO-IP, enter the domain name that
you have signed up on the DNS website, enter the username and
password, and then click Save.
