2. Click for the desired camera. In the Alarm Input window, select

Enable to enable alarm input.

3. Select the normally open (N.O.) or normally closed (N.C.) trigger

mode, and then click OK.

4. Click under Trigger Actions and then set action(s) to trigger. For

more details, see Alarm-Triggered Actions.

NOTE!

 The number of cameras that can be connected may vary with NVR

model.

 Actions that can be triggered may vary with alarm type.

5. Click under Arming Schedule and then set the time when

actions will be triggered.
