Chapter 4. Browser Operation

Note: Make sure that the port number you specify here matches the port

number used by the SNMP receiver computer.

4. Key in the community value(s) if required for the SNMP version.

5. Key in the auth/privacy password(s) that correspond to each of the

stations.

 Syslog Server

To record all the events that take place on eco PDU devices and write them to

the IP Control Box’s Syslog server, do the following:

1. Check Enable Syslog Server.

2. Key in the IP address and the port number of the Syslog server. The valid

port range is 1-65535. The default port number is 514.
