16
OPERATION / ADJUSTMENTS
Before the grinder is used, check condition of the grinding wheel.
Do not use chipped, broken or otherwise damaged grinding
wheels. Worn grinding wheel or brush should be immediately
replaced with new one before use. Once your work is completed,
you should switch o the grinder and wait until it comes to a
complete stop. Only then the grinder can be put aside. Do not
brake a rotating grinding wheel by pressing it against a workpiece.
• Do not overload the grinder. The weight of the power tool exerts
sucient pressure to eciently work with the tool. Overloading
and excessive pressure may lead to dangerous cracking of the
working tool.
• If the grinder is dropped during operation, it should be checked
and a working tool might need to be replaced, when it is
damaged or deformed.
• Never strike the workpiece with a working tool.
• Do not use the grinding wheel for hammering or stripping
of the workpiece, especially when corners, sharp edges are
worked, etc. (this may cause loss of control of the power tool
and recoil).
• Do not use discs from circular saws intended for wood cutting.
Failure to observe this recommendation may result in recoil of
the power tool, loss of control and may lead to injuries of the
operator.
SWITCHING ON /SWITCHING OFF
When the grinder is switched on and operated, it should be held
with both hands.
• Press the rear part of the switch (2).
• Move the switch (2) forwards - (towards the head) (g. C).
• Press the front part of the switch for continuous operation.
• The switch will be automatically locked in the position for
continuous operation.
• Press the rear part of the switch (2) to switch the tool o.
Once the grinder is switched on, wait until the grinding wheel
reaches maximum speed and only then you can begin to work.
During operation do not use the switch to switch the grinder on
and o. The grinder switch can be used only when the power tool
is moved away from the workpiece.
The tool is equipped with a switch with undervoltage release
feature. In case of temporary mains power failure or connecting to
mains socket with switch in ON position, the tool will not start. In
such case move the switch to OFF position and switch it on again.
SPEED ADJUSTMENT
The speed adjustment dial (8) (g. D) is located in the upper rear
part of the grinder casing. The adjustment range is from 1 to 6. The
rotational speed can be changed depending on your needs.
CUTTING
• The angle grinder can be used for cutting in a straight line only.
• Do not cut a workpiece holding it in your hands.
• Large workpiece should be supported. Make sure the support
points are located near the cutting line and at the ends of the
workpiece. A stably located workpiece will not tend to move,
when it is cut.
• Small workpieces should be fastened in a vice or using clamps,
for example. The workpiece should be fastened so that it is cut
near the fastening element. This will ensure higher cutting
precision.
• Do not allow the cut-o wheel to vibrate or jump, since this will
lower the quality of cutting and may cause the cut-o wheel to
break.
• Do not exert lateral pressure onto the cut-o wheel during
cutting.
• A proper cut-o wheel should be used depending on a
workpiece type.
• When a workpiece is cut, it is recommended that a cutting
direction is the same as rotation direction of the cut-o wheel.
The cutting depth depends on a wheel diameter (g. G).
• Only wheels with nominal diameters not larger than
recommended for a given grinder model should be used.
• Do not allow the fastening anges to contact a workpiece in case
of deep cuts (e.g. sections, building blocks, bricks, etc.).
Cut-o wheels reach high temperatures during operation. It
cannot be touched with uncovered body parts, before they cool
down.
GRINDING
Grinding wheel, cup-type grinding wheels, ap wheels, wheels with
abrasive bre, wire brushes and exible discs, etc. should be used for
grinding. Each type of discs and workpiece requires proper working
method and personal protective equipment.
Cut-o wheels should not be used for grinding.
Grinding discs are intended for removal of material with an edge
of the disc.
• Do not use the lateral surface for grinding. The optimum
working angle for this disc type is 30° (g. H).
• Works related to grinding can be performed only, when proper
grinding discs are used for a given workpiece.
When ap wheels, discs with abrasive bre and exible discs for
sandpaper are used, attention should be paid to the proper tool
angle (g. I).
• Do not grind with the entire surface of a wheel.
• This disc type should be used for working at surfaces.
Wire brushes are mainly used for cleaning sections and hard-to-
reach spaces. They can be used to remove rust, painting coats, etc.
from a workpiece surface (g. K).
Only such working tools can be used, whose permissible
rotational speed is higher or equal to the maximum no load speed
of the grinder.
OPERATION AND MAINTENANCE
Before any operations related to installation, adjustment, repairs
or maintenance are commenced, the plug of the power cord
should be disconnected from the socket.
MAINTENANCE AND STORAGE
• It is recommended to clean the tool after each use.
• Do not use water or other uids for cleaning.
• The tool should be cleaned with a dry piece of cloth or blown with
compressed air of low pressure.
• Do not use any cleaning agents or solvents, since they may
damage plastic parts.
• Venting slots in the motor housing should be cleaned on a regular
basis not to overload the tool.
• When the power cord is damaged, it should be replaced with
the power cord of the same parameters. It should be performed
by a qualied professional or the tool should be delivered to an
authorised service shop.
• When the commutator sparks excessively, have the condition of
motor carbon brushes checked by a qualied person.
• The tool should be always stored in a dry place and out of reach
of children.
REPLACING THE CARBON BRUSHES
Worn (shorter than 5 mm), burnt or cracked motor carbon brushes
should be immediately replaced. Both carbon brushes should be
always replaced at the same time.
