Applications and Network Service
Information
Epson Connect Service
By using Epson Connect service available on the Internet, you can print from your smartphone, tablet PC, or
laptop, anytime and practically anywhere.
e features available on the Internet are as follows.
Email Print Epson iPrint remote print Scan to Cloud Remote Print Driver
✓✓✓✓
See the Epson Connect portal website for details.
https://www.epsonconnect.com/
http://www.epsonconnect.eu (Europe only)
Web Cong
Web Cong is an application that runs on a Web browser, such as Internet Explorer and Chrome, from a computer
or smart device. You can conrm the printer status or change the network service and printer settings. To use Web
Cong, connect the computer or device to the same network as the printer.
Note:
e following browsers are supported.
OS Browser
Windows XP or later
Internet Explorer 8 or later, Firefox
*
, Chrome
*
Mac OS X v10.5.8 or later
Safari
*
, Firefox
*
, Chrome
*
iOS
*
Safari
*
Android 2.3 or later Default browser
Chrome OS
*
Default browser
*Use the latest version.
Running Web Cong on a Web Browser
1. Check the printer's IP address.
Press the network icon (for example
) from the home screen, and then check the printer's IP address.
User's Guide
Applications and Network Service Information
123
